e-LAN

Experience secure, scalable and cost-effective Ethernet multipoint connectivity with TPG Telecom's e-LAN.

Secure, scalable and cost-effective
Easily interact and share information
Bandwidths up to 10 Gbps

A group of people browsing internet using e-LAN service

Multipoint Layer 2 connectivity

Allowing geographically dispersed locations to easily interact and share business critical information, delivered over TPG Telecom's MPLS core network.

Call 13 42 02

Benefits of TPG Telecom's e-LAN

Secure

Each connection is given a unique encapsulation ID to create an ePipe that encapsulates all data and runs across TPG Telecom's private backbone.

High performance

Access speeds from 512K to 10Gbps (and higher in some locations), depending on Access technology and location.

Comprehensive reporting

Web-based reporting on availability, adherence to QoS profiles, latency, jitter and packet loss.

TPG Telecom's e-LAN provides:

The ability for you to completely manage your own routing schemes and CPE (Customer Premises Equipment)
The control and performance of a Layer 2 VLAN service. With meshed multipoint and secure networking at Layer 2, you can experience the increased performance that a non-routed network offers, coupled with maximum bandwidths of up to 10Gbps.
Quality of Service (QoS) options to ensure critical data is delivered within expected performance parameters. TPG Telecom's e-LAN is suitable for the most demanding enterprise requirements including voice and video conferencing applications.

TPG Telecom's e-LAN includes complete Layer 3 protocol transparency and is certified by the international Metro Ethernet Forum for compliance with their standards (MEF 9 and MEF 14 listed under TPG Telecom's subsidiary AAPT).

You can intelligently prioritise your traffic with 6 Classes of Service (CoS) available in 4 Quality of Service (QoS) packages:

Best Effort (BE) Only: all traffic is carried in the Best Effort CoS
Business Data (BD) Only: a simple business-grade CoS providing delivery assurance
Simple QoS: Access to all 6 CoS, with a combination of pre-determined priority queuing and weighted round-robin traffic handling
Flexible QoS: flexible customer defined bandwidth per CoS

Specifications

Configuration	Multipoint (full mesh)
Transport Technology	MPLS Core with various Access technologies
Access Networks	TPG Fibre (Fibre400/Fibre1000) TPG Ethernet NBN Other Third Party Access
Bandwidth	Flexible bandwidth options available ranging up to 10Gbps Bandwidth will depend on the Access speed
Quality of Service (QoS)	6 Classes of Service (CoS) available in 4 Quality of Service (QoS) packages: 1. Best Effort: all traffic is carried within the Best Effort CoS 2. Business Data: all traffic is carried within the Assured Delivery CoS 3. Simple: Access to all 6 CoS minus the complexity of defining traffic contracts for each 4. Flexible: fully flexible customer defined traffic contract per CoS QoS package is specified per site Simple and flexible QoS packages require customers to mark traffic (802.1p or DSCP)
Multicast	e-LAN services support Unicast, Broadcast and Multicast traffic.
MAC Learning Limit	The maximum number of unique MAC addresses per e-LAN is 250
Ethernet Frame Size (MTU)¹	Fast Ethernet interfaces: 1531 bytes Gigabit Ethernet interfaces: 8960 bytes 10 Gigabit Ethernet interfaces: 8960 bytes
VLAN Transparency¹	Customer VLANs are supported transparently²
Protocol Transparency¹	Layer 2/3 protocols are supported transparently³
Site Requirements	Rack space (1RU) and 240V AC 50Hz power to be provided by the customer
Reporting Access Availability and Performance Reporting	Optional per site QoS reporting
Provisioning Target	TPG On-Net Infrastructure: 4-7 weeks from Date of Order Acceptance
MEF Certification	MEF 2.0

¹ Access network dependant
² Where delivered via Ethernet Trunk Access the customer's equipment must support VLAN stacking
³ Where delivered via Ethernet Trunk Access the customer must tunnel Layer 2 control protocols

How it works
